Product Description:

Parameter Description
Height Accuracy (Electronic) 1.5mm (With Fiberglass RAB-Code Staves)
Distance Accuracy (Electronic) [<10m = +/-10mm] [10m to 50m = +/-.1%xD] [>50m = .2%xD]
Display resolution (Height) .0001 / .001m
Measuring Range 1.6 to 100m
Magnification 28x
Compensator Pendulum compensator with magnetic damping system
Data Storage 2000 points
Communications RS-232C
Dust/Water Protection IPX4
Operating Temperature -20 to +50ºC (-4 to +122ºF)
Operating Time More than 8.5 hours
Size W158 x D257 x H182mm (W6.2 x D10.1 x H7.2in)
Weight 2.4kg (5.3lb)
